Controls:
WARNING: The MARKBASS CASA is manufactured to be used in the country where they have been sold, and it is factory preset to that country’s voltage. So make sure you’re sending the correct voltage to your amp before you connect it to the AC power.
DIMENSIONS
- GAIN (range: -46 ÷ 23dB)
- BASS (level ±16 dB - freq 60 Hz)
- TREBLE (level ±16 dB - freq 5 kHz)
- 5 band equalizer (disabled by footswitch)
- (freq 67, 184, 510, 1400, 3800 Hz - level ±16 dB)
- INPUT: Impedance 500 Kohm/ Maximum Voltage 9 Vpp
- RETURN: Impedance 33 Kohm// Max 10Vpp
- LINE OUT: Balanced, Maximum Voltage 6 Vpp | (GND Lift - Level - Pre/Post)
- SEND: unbalanced, Max Voltage 20Vpp (Pre Eq)
- TUNER OUT: unbalanced, Max Voltage 2Vpp
- 300W RMS 8 ohm, 500W RMS 4 ohm
WARNING: The MARKBASS CASA is manufactured to be used in the country where they have been sold, and it is factory preset to that country’s voltage. So make sure you’re sending the correct voltage to your amp before you connect it to the AC power.
DIMENSIONS
- WIDTH: 18.97”/ 48.2 cm
- HEIGHT: 8.03”/ 20.4 cm
- DEPTH: 10.82”/ 27.5 cm
- 14.10 lbs / 6.4 Kg
