SPECIFICATIONS:
- Power 800w
- Series Signature
- Size S
- Preamp Solid state
TECHNICAL FEATURES
INPUTS
- INPUT: impedance 500 Kohm, max. voltage 9 Vpp
- EFFECT RETURN: impedance 33 Kohm, max. voltage 10 Vpp
CONTROLS
- GAIN: -46 dB to +23 dB range
- MASTER VOLUME
- LINE OUT LEVEL
- MUTE switch
- GROUND LIFT (switch on rear panel)
- PRE/POST EQ (switch on rear panel)
- FSW input for (optional) footswitch to turn on/off EQ1 and EQ2
EQUALIZATION - EQ1
- ULTRALOW: Level ±16 dB (Freq. 65Hz)
- LOW: Level ±16 dB (Freq. 180Hz)
- MID: Level ±16 dB (Freq. 500 Hz)
- HIGH MID: Level ±16 dB (Freq. 1.4 KHz)
- HIGH: Level ±16 dB (Freq. 3.8 KHz)
EQUALIZATION - EQ2
- OLD SCHOOL: Variable LOW PASS From 20KHz to 200Hz
- MILLERIZER: 5-12 KHz BAND PASS Filter (Level 0 /+10 dB)
OUTPUTS
- LINE OUT: balanced XLR, max. voltage 20 Vpp
- EFFECT SEND: unbalanced, max. voltage 20 Vpp (pre-EQ)
- TUNER OUT: unbalanced, max. voltage 2 Vpp
- SPEAKER OUT: speakon combo
OTHER
- WEIGHT: 6.61 lbs / 3 Kg
- WIDTH: 10.87 in. / 27.6 cm
- DEPTH: 9.84 in. / 25 cm
- HEIGHT: 3.27 in. / 8.3 cm
- OUTPUT POWER: 800W RMS @ 4 ohms / 500W RMS @ 8 ohms
- POWER REQUIREMENT:100/120V; 230V; 240V – 50/60Hz
