- Body: Poplar
- Bolt-on neck: Maple
- Fretboard: Jatoba
- White dot fretboard inlays
- Neck profile: GRX (width at 1st fret: 19.5 mm - width at 12th fret: 21.5 mm)
- Scale: 648 mm (25.51")
- Fretboard radius: 305 mm (12.01")
- Nut width: 42 mm (1.65")
- Plastic nut
- 22 Medium frets
- Pickups: Infinity RS humbucker (bridge) and 2 Infinity RS single coils (middle and neck)
- 1 x Volume and 1 x tone control
- 5-Way switch
- White pickguard
- T106 tremolo
- Ibanez machine heads
- Chrome hardware
NECK DIMENSIONS
- Scale : 648mm/25.5"
- a : Width 42mm at NUT
- b : Width 57mm at 22F
- c : Thickness 19.5mm at 1F
- d : Thickness 21.5mm at 12F
- Radius : 305mmR
SWITCHING SYSTEM
CONTROLS
FEATURES
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
