Features
Technical Specifications
- Components and construction
- 3.5-inch (89 mm) woven composite low-frequency transducer
- 1-inch (25 mm), ultra-low-mass, silk-dome, high-frequency transducer
- Rear-firing acoustic port for superior bass-frequency reproduction
- Optimized, resonance-suppressing internal bracing
- User controls
- High- and low-frequency tuning controls
- Front-panel Volume control for speakers and headphone amplifier
- Power and safety
- 50 watt (25W/side), Class AB biamplification
- RF interference, output current limiting, over-temperature, transient, and subsonic protection
- Amplifier “soft start” feature eliminates popping on power-up
- Internal power supply with IEC connector
- Power switch with on/off LED
- Inputs and outputs
- Balanced ¼-inch TRS, unbalanced 1/8-inch stereo, and RCA inputs
- Integrated stereo headphone amplifier with front-panel 1/8-inch output
- Included Accessories
- Speaker wire
- 1/8" TRS to Stereo RCA cable
- Stereo RCA to Stereo TS cable
- Studio One Prime and Studio Magic Software Suite ($1000 value!)
Technical Specifications
- Inputs
- 1- Stereo 1/8"
- 2- Balanced ¼” TRS
- 2- Unbalanced RCA
- Frequency Response 80 Hz - 20 kHz
- Crossover Frequency 2.8 kHz
- Amplifier Power 25W/speaker
- LF Driver 3.5"
- HF Driver 1” silk dome
- Peak SPL (@ 1 meter) 100 dB
- Input Impedance 10 kΩ
- Volume Range A-type taper
- MF Control Variable (-6 to +6 dB, center 100 Hz)
- HF Control Variable (-6 to +6 dB, center 10 kHz)
- RF interference
- Output-current limiting
- Over-temperature
- Turn-on/off transient
- Subsonic filter
- External mains fuse
- 100-120V ~50/60 Hz or 220-240V ~50/60 Hz
- Vinyl-laminated, medium-density fiberboard
- Width 5.6" (141 mm)
- Depth 6.4" (162 mm)
- Height 8.3" (210 mm)
- Weight (per pair) 6.4 lb. (2.9 kg)
